NovaStar MCTRL 4K LED Display Controller

Description NovaStar MCTRL 4K The NovaStar MCTRL 4K is an ultra-large load LED display controller. A single Novastar MCTRL 4K features a loading capacity of up to 4096×2160@60Hz. It supports any resolution customized with the maximum width or height up to 7680 pixels, meeting the on-site configuration requirements for ultra-long or ultra-large LED screens.   It supports HDR, individual gamma adjustment for RGB, low latency, 3D, and pixel level brightness and chroma calibration. It improves the brightness, grayscale and color performance of the display in many aspects, presenting more uniform, detailed and vivid images. SPECIFICATION Control  Ultra Large Capacity, Resolution 4K x 2K@60Hz  Resolution up to 8K width  Detailed control of Video Walls via LCTMars PC-Software or SmartLCT Mac OS X Software  Multiple Video Inputs  Multiple Outputs : 16 RJ 45 Ports & 4 Optical output ports  Screen Configuration via Web Interface  Wireless Remote Control  Can be cascaded via USB or GenLock for huge screens Resolution  Max resolution capacity : 8.3 million pixels  4096 x 2160@60Hz  7680 x 1080@60Hz  12bit/10bit/8bit HD Video Source  Supports HDCP, 1080i/P, 480i, 576i, 720P, PAL/NTSC, HDR (HDR10&HLG)  Support Ultra-High Resolution settings with NVIDIA Graphic Cards  Supports both Mosaic and Multi-Card working modes for Dual-Link DVI inputs  Supports 3D function when working with the 3D emitter EMT200 and 3D glasses Construction  Aluminium Metal Housing  Rack Mountable Electrical  Multi-voltage operation: AC 100-240V, 50/60Hz  Power Draw: 30W  Operating Temperature: -20°C – 60°C Connections Inputs 2x Dual DVI-D, up to 8.3 million pixels 1x HDMI 2.0, up to 8.8 million pixels per input 1x DP 1.2, up to 8.8 million pixels per input 1x RJ45 Network LAN Connector for IP-based Control 1x Locking IEC Power connector Outputs 16x RJ45 4Gigabit Ethernet Screen outputs 4 x Optical Screen Output 1x Genlock Loop Loop  USB 2x USB Type A port to connect USB Stick or cascade OUT 1x USB Type B control interface for connection with PC or Cascade IN  DP, HDMI, USB, DVI, CAT5 & Power cable included Dimensions & Weight  Dimensions (LxWxH): 482.6 x 372 x 96mm  Weight: 4,6 kg. DOWNLOADS NovaStar MCTRL 4K Specifications Sheet
