Novastar MCTRL300 Independent Controller

Description Novastar MCTRL300 Independent Controller The Novastar MCTRL-300 is a compact basic sender box which makes setting up your Novastar equipped LED screen easy and simple. Encased in a sturdy housing the Novastar MCTRL300 incorporates not only a DVI and audio input but also an onboard light sensor input. This can be used to connect a Novastar light sensor directly to the sending card for automatic brightness adjustment when ambient lighting changes. By adding the MCTRL-300 to your LED screen setup you will have the instant ability to play any content of your PC directly on the LED screen.   Specification: Inputs Single Link DVI: 1 Extra Features: Scaling Function: No Control and Programming Control System: Novastar Maixmum Loading Capacity: 1.3 millions pixels Maixmum Input Resolution: Width and Height can be defined by users Electrical Specifications and Connections Power Supply: 100-240 V AC 50-60 Hz Power Consumption: 16 W Power Connector In: IEC Data Connector Out: RJ45 Thermal Specifications Maximum Ambient Temperature: 60 °C Minimum Ambient Temperature: -20 °C Operating Humidity: 0-95 %rH Downloads Novastar MCTRL300 LED Display Controller Specification Sheet
