NovaStar NovaPro UHD LED Video Controller

Description Novastar NovaPro UHD LED Video Controller The NovaPro UHD LED Video Controller is the latest all-in-one controller product launched by Nova, with video processing and video control functions, and integrated Master VI platform software. Users can connect the mouse, keyboard and monitor to NovaPro UHD and directly perform layer management, screen configuration and other operations.   The NovaPro UHD can receive a variety of video signals and has ultra-high-definition full 4K×2K@60Hz and 8K×1K@60Hz image processing capabilities. It can carry a maximum load of 10.4 million pixels and can send the processed video through the Neutrik network port and optical fiber port. to the LED display.   With powerful video processing and sending capabilities, NovaPro UHD is widely used in high-end rental, stage control and engineering small-pitch LED display fields. SPECIFICATION Features   6 x layers – Supports for mulitiple layers like: 2 x 4K × 2K and 4 x 2K × 1K, LOGO, and BKG, as well as irregular shaped layers – Flexible layer adjustment, including opacity, mask, overlapping, copying, mirroring, flipping, etc. – Irregular layer supported – Z-order sorting  1 x OSD, 1 x LOGO and 1 x BKG – OSD supports cropping, opacity adjustment, dynamic and static images, and position settings. – LOGO supports resolutions up to 256×256 and allows for cropping, opacity adjustment, and position settings. – BKG can be scaled to fit the screen automatically. Built-in Master VI platform software allowing for easier operations Working with the A8s or A10s Plus receiving the card to support HDR function, making images smoother Low latency output – The end-to-end delay can be as low as 1 frame when the low latency and synchronization functions are turned on, and the data runs vertically on the screen.  Multiviewer settings – Monitor the input sources, PVW or PGM, or perform mixed monitoring. Web control – Access and control the NovaPro UHD in real-time by using a browser without the need to install multiple pieces of software. Up to four NovaPro UHD units can be linked together for image mosaic. Decimal frame rates supported – The supported frame rates are 23.98 Hz, 29.97 Hz, 47.95 Hz, 59.94 Hz, 71.93 Hz, 119.88Hz, and 143.86Hz. Genlock synchronization, fit for XR application scenarios PGM editing supported Construction  Aluminium Metal Housing  Rack Mountable Electrical  Multi-voltage operation: AC 100-240V, 50/60Hz  Power Draw: 180W  Operating Temperature: -10°C – 60°C Control 1 x Ethernet Port 3 x USB 1 x Genlock IN-LOOP 1 x Control UI Connections Inputs 2x Dual DVI-D, up to 8.3 million pixels 1x HDMI 2.0, up to 8.8 million pixels per input 1x DP 1.2, up to 8.8 million pixels per input 1x RJ45 Network LAN Connector for IP-based Control 1x Locking IEC Power connector Outputs 16 x Neutrik Ethernet outputs 4 x Optical Screen Output 1 x MVR 1 x AUX  USB 2x USB Type A port to connect USB Stick or cascade OUT 1x USB Type B control interface for connection with PC or Cascade IN  DP, HDMI, USB, DVI, CAT5 & Power cable included Dimensions & Weight  Dimensions (LxWxH): 482.6mm × 183.9mm × 497.5m  Weight: 21kg. DOWNLOADS NovaStar NovaPro UHD Specification Sheet
