NovaStar V700|V760 LED Video Controller

Description Novastar V700 LED Video Controller   Novastar V700 is a professional 2-in-1 LED display controller with video processing and LED display control. Novastar V700 supports maximum load is 1.3 million pixels,input resolutions up to 1920 × 1200 @ 60Hz and has a complete video input interface,including 2 CVBS, 1 VGA, 1 DVI, 1 HDMI. Novastar V700 powerful image processing,image control and friendly interface have made LED display control more easier. Novastar V700 can scale the input image point by point according to the resolution; Specifications Product Type: Video Wall Controller Load capacity: 1.3 million pixels Maximum output resolution: 1280×1024, 1440×900 Video input interface: CVBS × 2, VGA × 1, DVI × 1, HDMI × 1 Control method: USB, serial port control (RJ45 interface) Video source bit depth: 10bit / 8bit Source switching effects: One-click switching Support zoom: support Support splicing:None Picture in Picture: Support Custom EDID:None LED Out: two network port Support loop-out:None Video output loading capacity: 1280×1024, 1440×900, (1.3 million pixels); Provide seamless fast-cut and fade-in switching effects to enhance high quality picture; The position and size of the picture-in-picture can be adjusted as you like; Support point-by-point calibration technology; One-click switch of video source; HDMI audio input; external independent audio input; Support high-level video input, 10bit / 8bit; With Nova G4 engine, the picture is more stable without flickering, no scanning lines; No need software configuration; An intuitive LCD display interface and clear key light prompts simplify system control.     Novastar V760 LED Video Controller   Novastar V760 video display controller is a simple and 2-in-1 video processor.It supports HD multi-type interface input,CVBS × 1, VGA × 1, DVI × 1, HDMI × 1, USB × 1. Novastar V760 LED video processor integrates powerful LED display control technology and video processing to simplify application of LED display. It is usually used for shopping malls, hotels, exhibitions, television studios and other application. Specifications Product Type: Video Display Controller Load capacity: 1.3 million pixels Maximum output resolution: 1280×1024, 1440×900 Video source bit depth: 10bit / 8bit Video input interface: CVBS × 1, VGA × 1, DVI × 1, HDMI × 1, USB × 1 Source switching effects: One-click switching Support zoom: support Support splicing: None Picture in Picture: None Custom EDID: Support LED Out: two channel network port Control method: USB, serial control Support loop-out: None Supports 5 kinds of input interfaces, including 1 DVI, 1 HDMI1.3, 1 VGA, 1 USB playback, 1 CVBS, optional 1 expansion card. Support input resolution presets and custom adjustments. After the expansion card is installed, the mouse can control the expansion card. Support window position, size adjustment and window interception. Support one-click switch of input source. Support external audio. Supports 2 network port outputs with maximum load of 1.3 million pixels. Support screen parameters adjustment, such as brightness,Gamma, etc. The intuitive LCD display interface on the front panel and clear key light prompts simplify the system’s control operations. Support to create 6 piece of user templates. Supports three zoom modes: full-screen zoom, point-to-point display and custom zoom. Support quick click screen, simple configuration. Supports connecting video console controller.     Production function comparison Type V700 V760 V900 V960 V1060 V1260 Load Capacity 1.3 million 1.3 million 2.3 million 2.6 million 3.9 million 10.4 million Wide high limit The widest 3840 Up to 1920 The widest 3840 Up to 1920 The widest 3840 Up to 1920 The widest 3840 Up to 1920 The widest 4096 Up to 4096 The widest 16384 Up to 8192 Input interface VGA x1, DVI x 1, HDMI x 1, CVBS x 2 VGA x1,DVI x 1 , HDMI x 1, CVBS x 1 USB x 1 VGA x2,DVI x 1 , HDMI x 1, CVBS x 2 YPBRR x 1 VGA x1,DVI x 1 , HDMI x 1, CVBS x 1 USB x 1 VGA x1,DVI x 1 , HDMI x 2, CVBS x 2 3G-SDI x 1 DVI x 4 , HDMI2.0 x 1, CVBS x 2 3G-SDI x 1 Wireless screen projection U disk playback – √ – √ √ – Output Interface Network port x 2 Network port x 2 Network port x 4, DVI Loop DVI x 1, VGA x 1 Network port x 4 Network port x 6, DVI Loop DVI x 1, Network port x 16, 10G fiber X 4 DVI x 1, HDMI x 1 Splicing with load – – √ – – – Number of layers 2 1 2 1 3 1 OSD 5 Number of scenes – 6 10 6 10 10 Knob brightness adjustment √ √ √ √ √ √ Onboard U disk playback – √ – √ – – Way to control USB USB USB USB USB TCP/IP USB TCP/IP Central control docking RS232 RS232 RS232 RS232 TCP/IP RS232
