NovaStar V900|V960 LED Video Controller

Description Novastar V900 LED Video Controller   Novastar V900 is a professional LED display controller with LED display sending control and powerful front-end video processing functions. Novastar V900 meets the needs of led screen industry with excellent quality and flexible image control. Novastar V900 has variety video input interface, including 2 CVBS, 2 VGA, 1 DVI, 1 HDMI, 1 YPbPr,Max support input resolutions up to 1080p @ 60Hz. V900 also can scale the image point by point according to resolution. Novastar V900 adopts innovative architecture to realize intelligent configuration.,you only need to operate a knob and a button to complete the system configuration and greatly reducing stage preparation time; Novastar V900 has powerful image processing, professional image control, and friendly interface, making LED display control work became easier. Specifications Novastar video controller V900 Product Type: LED video controller Load capacity: 2.3 million pixels Video input interface: CVBS × 2, VGA × 2, HDM × 1, DVI × 1, YPbPr × 1, SDI × 1 (optional) Maximum output resolution: 2048 × 1152 Support stitching: seamless stitching Control method: USB serial port cascade Picture in Picture: Support Support zoom: support Support loop-out: professional DVI loop-out LED Out: four network ports Source switching effects: Support Custom EDID: Support Video source bit depth: 10bit / 8bit An intuitive LCD display interface and clear key light prompts simplify system installation and control; The position and size of picture-in-picture can be adjusted as you like; HDMI / DVI video input, HDMI audio input; Support Nova’s new generation of point-by-point calibration technology; Video output loading capacity: 2.3 million pixels, supported video formats: RGB, YCbCr4: 2: 2, YCbCr4: 4: 4; Provide seamless fast-cut and fade-in switching effects to enhance display picture; With Nova G4 engine, stable picture is without flickering, no scanning lines, nature images; White balance calibration and color gamut matching are implemented to ensure the true color image; Support high-level video input, 10bit / 8bit;     Novastar V960 LED Video Controller   Novastar V960 video controller is a simple,multi-functional 2-in-1 video processor with maximum load of 2.6 million pixels. It supports high-definition input of multiple types of interfaces,DVI × 1, HDMI1.3 × 1, VGA × 1, USB playback × 1, CVBS × 1. Novastar V960 integrates professional LED display control technology and powerful video processing  into one.It is usually used for shopping malls, hotels, exhibitions, television studios and other application. Specifications Two-in-one controller V960 Product type: 2-in-1 controller Source switching: None Support zoom: support Picture in Picture: None Support splicing: None Custom EDID: Support Maximum output resolution: maximum width 3840 pixels; maximum height 1920 pixels Video input interface: DVI × 1, HDMI1.3 × 1, VGA × 1, USB playback × 1, CVBS × 1, optional expansion  card × 1 LED Out: 4 Gigabit Ethernet ports Load capacity: 2.6 million pixels Support loop-out: None Control method: USB, serial control Video source bit depth: 10bit / 8bit Support one-click switch of input source. Support external audio. Supports one-click full-screen zoom, point-to-point display, and custom zoom. Support up to 5 input interfaces, including 1 DVI, 1 HDMI1.3, 1 VGA, 1 USB playback, 1 CVBS, 1 optional expansion sub-card. Support DVI and HDMI input resolution presets and custom adjustments. Support window position, size adjustment and window interception. Support quick click screen, simple screen configuration. Supports 4 network port outputs with maximum load of 2.6 million pixels. Support screen parameters adjustment, such as brightness, Gamma, etc. The intuitive LCD display interface on the front panel and clear key light prompts simplify the system’s control operations. Supports creating 6 pieces of templates to easy use. Support to connect central control equipment through RS232.   Production function comparison Type V700 V760 V900 V960 V1060 V1260 Load Capacity 1.3 million 1.3 million 2.3 million 2.6 million 3.9 million 10.4 million Wide high limit The widest 3840 Up to 1920 The widest 3840 Up to 1920 The widest 3840 Up to 1920 The widest 3840 Up to 1920 The widest 4096 Up to 4096 The widest 16384 Up to 8192 Input interface VGA x1, DVI x 1, HDMI x 1, CVBS x 2 VGA x1,DVI x 1 , HDMI x 1, CVBS x 1 USB x 1 VGA x2,DVI x 1 , HDMI x 1, CVBS x 2 YPBRR x 1 VGA x1,DVI x 1 , HDMI x 1, CVBS x 1 USB x 1 VGA x1,DVI x 1 , HDMI x 2, CVBS x 2 3G-SDI x 1 DVI x 4 , HDMI2.0 x 1, CVBS x 2 3G-SDI x 1 Wireless screen projection U disk playback – √ – √ √ – Output Interface Network port x 2 Network port x 2 Network port x 4, DVI Loop DVI x 1, VGA x 1 Network port x 4 Network port x 6, DVI Loop DVI x 1, Network port x 16, 10G fiber X 4 DVI x 1, HDMI x 1 Splicing with load – – √ – – – Number of layers 2 1 2 1 3 1 OSD 5 Number of scenes – 6 10 6 10 10 Knob brightness adjustment √ √ √ √ √ √ Onboard U disk playback – √ – √ – – Way to control USB USB USB USB USB TCP/IP USB TCP/IP Central control docking RS232 RS232 RS232 RS232 TCP/IP RS232
