NovaStar VX400|VX600|VX1000 LED Video Controller

Description Novastar VX1000 LED Video Controller The VX1000 LED Video Controller is NovaStar’s new all-in-one controller that integrates video processing and video control into one box. It features 10 Ethernet ports and supports video controller, fiber converter and Bypass working modes. A VX1000 unit can drive up to 6.5 million pixels, with the maximum output width and height up to 10,240 pixels and 8192 pixels,respectively, which is ideal for ultra-wide and ultra-high LED screen applications.   VX1000 LED Video Controller is capable of receiving a variety of video signals and processing high-resolution 4K×1K@60Hz images. Additionnaly, the device features stepless output scaling, low latency, 3D, pixel-level brightness and chroma calibration and more, to present you with an excellent image display experience. Besides the built-in sending card with 10 Ethernet ports, VX1000 LED video controller offers the option to install an SFP module. With these you can cover bigger distances than the 100-metre limit of Ethernet cables and drive another VX1000, which then drives your LED screens. The second fibre output serves as a backup and is automatically used in case something happens to the main output (“Output 1”).   With powerful video processing and sending capabilities and other outstanding features, the VX1000 LED Video Controller can be widely used in applications such as medium and high-end rental, stage control systems and fine-pitch LED screens   Features 3 Working modes available: including video controller, bypass mode, and fiber converter; Stable and safe redundant system: redundant input source, system configuration, ethernet ports, and devices are all supported; 3-layer images: 3 x 4K layers, free scaling for each layer; 4K High-definition visual performance: 4K x 1K@60Hz high resolution input, 4K x 1K point to point display; Large loading capacity: 10 Ethernet output ports supporting up to 6.5 million pixels of loading capacity;   Strong video processing: With a single click, full-screen display can be achieved; Utilizing the advanced image quality processing technologies of SuperView III, it enables seamless output scaling without steps; It allows for flexible input cropping, giving you the freedom to crop the input as desired. Mosaic input source: Mosaic sources can be used to mask identities, hide sensitive content, or protect personal information, among other purposes; Nova VX1000 supports a mosaic source composed of several input connectors of the same type. Easy preset saving and loading: Up to 10 user-defined presets supported Load a preset by simply pressing one button       VX1000/VX600/VX400 Video Controller Specification Device Model VX1000 VX600 VX400 Loading Capacity 6.5 million pixels 3.9 million pixels 2.6 million pixels Max Width & Height  Max width: 10240 pixels Max height: 8192 pixels Layers 3x 4K×1K 3x 2K×1K 2x 2K×1K Input Connectors 1x 3G-SDI 2x HDMI 1.4 2x DVI（HDMI 1.4） 1x OPT1 1x 3G-SDI 2x HDMI 1.3 1x DVI 1x OPT1 1x 3G-SDI 2x HDMI 1.3 1x DVI 1x OPT1 Output Connectors 10x Ethernet Ports 1x HDMI1.3 1x HDMI1.4 LOOP 1x DVI LOOP 1x 3G-SDI LOOP 2x OPT 6x Ethernet Ports 1x HDMI1.3 1x HDMI1.3 LOOP 1x DVI LOOP 1x 3G-SDI LOOP 2x OPT 4x Ethernet Ports 1x HDMI1.3 1x HDMI1.3 LOOP 1x DVI LOOP 1x 3G-SDI LOOP 2x OPT Presets 10 10 10 Control Connectors 1x Ethernet Port 2x USB (input & output) 1x GENLOCK (IN & LOOP) 1x Ethernet Port 2x USB (input & output) 1x GENLOCK (IN & LOOP) 1x Ethernet Port 2x USB (input & output) 1x Light Sensor   DOWNLANDS Novastar VX1000 LED Video Controller Specification Sheet Novastar VX600 LED Video Controller Specification Sheet Novastar VX400 LED Video Controller Specification Sheet
