HDL Panel SOURCE 7 Touch Screen Black
Roll over image to zoom in
$ 90.76
Description Output channel : KNX interface: 2CH, 5A/CH Resistive load: ≤660W/CH Capacitive load: ≤200W/CH Communication protocol: HDL LINK, WiFi, RJ45 Master chip: PX30 Storage capacity: 2 8GB Operating frenquency: 2.4GHz, 5GHz Operating system : Android Ethernet interface: RJ45 TF card : Max 64GB Touch screen: 7-inch capacitive touch screen, available for multi-touch; Resolution: 1280*720 Knob: Users can turn the knob to adjust the light brightness, curtain open/close percentage, media volume, temperature, or fan speed. Knob-operated control: turn clockwise/counter-clockwise, short press, long press. The knob lighting is with RGB lamp beads. Camera: 5-megapixel camera; manual-operated on/off Microphone: Four microphones are located at the top of the touch screen. The voice detecting range is within 3m around the touch screen. Speaker: Dual speaker, 0.8W*2 Proximity sensor : Once the sensor detects near human motion, touch screen automatically wakes up. The detecting range is within 15cm around the touch screen. Temperature & humidity sensor: Real-time monitor environment status Knob-operated control, including turn clockwise/counter-clockwise, short press, long press Temperature & humidity monitoring: built-in temperature & humidity sensor for monitoring real-time environment status. Proximity detection: Built-in proximity sensor for detecting human motion. Once the sensor detects near human motion, the touch screen automatically wakes up. Requires Power Interface MPWS2R1ETH-KT.18 (not included) https://www.mstronics.com/p/22235/hdl-mpws2r1eth-kt-18-source-knx-interface.html
